1.The machine adopt with synchronous belt drive and hard gear face gear box. The gear box adopt with synchronous belt drive each printing group high precision planetary gear oven(360 º adjust the plate) gear driving the press printing roller
2.After printing, long running material space ,it can make the ink drying easily,better results
|
TYPE |
4-1400 TYPE |
4-1300 TYPE |
4-1200 TYPE |
4-1000 TYPE |
4-800 TYPE |
|
Max. Printing material width |
1400mm |
1300mm |
1200mm |
1000mm |
800mm |
|
Max. Printing width |
1360mm |
1260mm |
1160mm |
960mm |
760mm |
|
Max. Unwinding diameter |
1300mm |
1300mm |
1300mm |
1300mm |
1300mm |
|
Max. Rewinding diameter |
1300mm |
1300mm |
1300mm |
1300mm |
1300mm |
|
Printing length range |
230-1000mm |
230-1000mm |
230-1000mm |
230-1000mm |
230-1000mm |
|
Printing speed |
5-100m∕min |
5-100m∕min |
5-100m∕min |
5-100m∕min |
5-100m∕min |
|
Register precision |
≤±0.15mm |
≤±0.15mm |
≤±0.15mm |
≤±0.15mm |
≤±0.15mm |
|
Thickness of plate (including the thickness of double sides glue) |
2.28mm+0.38mm |
2.28mm+0.38mm |
2.28mm+0.38mm |
2.28mm+0.38mm |
2.28mm+0.38mm |
|
Dimension |
8200*2300*2500 |
8200X2300X2500 |
8200X2250X2500 |
8200X2100X2500 |
8200X1900X2500 |
|
Weight (approx.) |
6.5T |
6.1T |
5.58T |
5.1T |
4.5T |
|
Power |
24KW |
21KW |
21KW |
21KW |
19KW |
