HSR-950 Flexo Printing Machine (Four Color)

HSR-950 Flexo Printing machine (four color)
HSR-950 Flexo Printing machine (four color)

Basic Configuration

1) One set of unwinding unit
• Max Paper roller diameter 1500mm
• One 3inch air swelling shaft can change 6 inch air swelling shaft
• Auto tension control system of unwinding and rewinding ( Mitsubishi ) one Magnetic powder brake.
• Fast inflating gun
2) One set rewinding system
A set of winding for rewinding after printing, with One 3inch air swelling shaft can change 6inch air swelling shaft
•Max rewinding diameter 1400mm
3) Web Guiding
• One set of Paper binding table
• The paper guide roller adopts high hardness anodized
• Adopt the ball screw electric actuators
• Adopt rectifying photoelectric head to rectify induction
• Electronic paper web guide traction device, there was a small offset paper web movement, the system can accurately continuously revised
• Closed-loop control system
• Test method: edge
• Rectification precision:±0.12mm
4) One set of adjustable feeding paper system (Dual pressure roller)
• Dual pressure roller pressure feeding together
• Printing paper tension adjusted
5) Four Color printing unit
•The printing unit adopt 45 degrees of DP13 helical gear structure
• Reserved image detection station
• Anilox rolle, printing roller pressure pneumatic clutch
• Ceramic Anilox roller (as require)
• Priting roller 4pc .(as require)
• Manual transverse focusing alignment 4 set
• Manual vertical focusing alignment 4 set
• Single pole reverse scraping system 4set
• Stainless steel cartridge 4set
• Fast changing plate cylinder without any tools
• Anilox roller rotation function: when stop anilox roller running automatically, to prevent ink dry on anilox roller, avoid the anilox roller plug.
• 4 The printing gear:cp1/8
6) IR Dryer (one set)
    Infrared heating drying printing unit,IR 4set
7) Back Tension controller system
    Dual pressure roller sending paper
8) Plate Mounter (1set)
• On ordinary Plate Mounter, including bilateral symmetry points and 10 times the magnifying glass
• For version, in order to achieve multi-color overprint accurately
• Used for products with quick replacement products
9) One tool box

Code

Description

ART NO.

Each dosage

Manufacturer

T1

Tension controller (Rewinding)

ST-3600

1

楚鹰科技

T2

Tension controller
(Unwinding)

LE-30CTA

1

Mitsubishi

DC

Web guiter

FV800

1

KCOM



Converter

ATV312HU40N4

1

Schneider



Converter

ATV312HU55N4

1

AC1

a c contactor

LC1E40

1

AC1

a c contactor

LC1E1810

1



Phase sequence protector

JVRD

1





Mini relay

RXM 24VDC

1



Time relay

H3Y

1

OMRON

PLC

FP-X0L14R

1

Panasonic

Solid State Relay

KSB80D40L

4

KUDOM

Machine tool control transformer

JBK3-63

1

CHNT

BKN

Breaker

BKN D10

2

LS

BKN

Breaker

BKN D25

3

BKN

Breaker

BKN C32

2

BKN

Breaker

BKN C63

1



Ceramic anilox roller

FZ100K 100N.M DC24V 2A

4

AUCLEAN(SHANGHAI)

Magnetic powder clutch

2

瑞安华光



Meter coun ter



1

中星工控



Switching Power Supply



1

Schneider



Solenoid valve

GR200-08

1

AirTAC



Hydraulic pump



1

Hongxing yeya

M1

Main motor

5.5kw 380v

1

上海瑞域 5.5KW

M2

Precision gear motor

4GN-30-K

1



M3

Unwinding motor

YES-132M-6 4Kw
380V

1

上海恒列电机

Technical parameter

Code

Main Technical Parameter

HSR-950

1

Max Feeding Width

1400mm

2

Printing Length

190mm—420mm,

3

Max Web Width

950mm

4

Max printing Width

930mm

5

Main Motor Power

5.5KW

6

Power Supply

380V 3PH 50Hz

7

Printing Speed

0—70m/Min

8

Paper Thickness

1.7mm

9

Paste version tape thickness

0.38mm

10

The thickness of the substrate

180g-420g

11

Overprint precision

±0.12mm

12

Total Power

30KW

13

Machine dimension

3*2.8*1.7m

14

Machine weight

About 5.5 吨

Prepare Parts List

code

Description

Model

Quantity

1

IR Lamp



9pcs

2

Button

Green

2pcs

3

Button

Black

2pcs

4

a . c . contactor



1pcs

5

straight-through joint

APU 6

2pcs

6

straight-through joint

APU 8

2pcs

7

pressure -regulator vavle

SR200-08 (无表、无
架)

1pcs

8

Solenoid valve

220V
4V210-08-DC220V

1pcs

Shipment items

01) – Price terms:
02) - Shipment: by sea
03) - Delivery time: within 60 workdays after 30% deposit
04) - Package: wooden case
05) -Installation, adjusting & commissioning: If the buyer need us send engineer for install or adjusting, the buyer should take on all costs, required during our technician's stay in the buyer's country, round airplane tickets, accommodation, foods, the engineer’s salary is 80usd/ day
06) Guarantee terms: the seller guarantee the machines are new (or unused) and the guarantee period will be given 12 (twelve) months which starts from the date of the machine's arrival. During this period, the seller will provide free maintenance and free spare parts that caused by the machine's quality, But the buyer must pay the round trip tickets and accommodation expenses for seller's technicians, the engineer’s salary is 80usd/ day
